Span wise load carrying Capacity (Kg/m2) for deck shuttering.

Deflection Limits to be - (L/180).

Yield Strength

240 Mpa

350 Mpa

Thickness

0.6

0.8

1

1.2

0.6

0.8

1

1.2

Span

Spacing (m)

Single

1

919

1462

2073

2704

1131

1860

2638

3496

1.4

439

746

1057

1379

577

949

1346

1784

1.8

284

451

640

835

349

574

814

1079

2

229

366

518

676

283

465

655

832

Double

1

841

1359

1893

2432

1032

1717

2459

3211

1.4

447

718

1008

1303

550

910

1297

1705

1.8

276

441

621

806

339

559

796

1049

2

224

359

506

657

276

455

647

854

Multi

1

960

1558

2161

2766

1177

1964

2820

3669

1.4

516

830

1162

1499

634

1050

1500

1967

1.8

319

511

720

932

393

649

924

1217

2

260

417

587

761

320

529

752

992
